Sunshine Y22 Plus 16 Inches Unlimited Times Film Cutting Machine Plotter

Sunshine Y22 Plus 16-inches Unlimited Times High Precision Smart Film Cutting Machine

Features:

• Y22 Plus 16-inches unlimited times film cutting machine, large machine, suitable for larger size hydrogel films, unlimited times, unlimited films
• Supports precise cutting of hydrogel film/color film below 16 inches
• There is no limit to the number of cuttings and film products, films up to 16 inches can be cut and adapted to various electronic devices
• The machine can be connected to WiFi for touch control operation, and the mobile phone can be connected to APP for remote operation through Bluetooth
• It has an independent operating system, a complete range of models, and real-time data updates
• 5.0-inch large screen intelligent operating system, high-definition large-size touch screen, convenient and easy to operate
• Hundreds of film products, efficient experience, integrated design, one-click film cutting, one-hand control, easy film cutting
• High precision cutter head, split type, adjustable depth; replaceable cutter head, press to remove the cutter head
• Five-wheel lamination roller, film running is smooth and cutting is more accurate
• Elastic pressure rod, film feeding is adjustable, double spring uniform film rod, stable film pressing effect
• Automatic film feeding, infrared sensor, automatic transmission; materials to the designated location, convenient and fast
• Free language switching, the system supports more than 80 different languages, and you can switch languages freely with one click

Specification:

• Brand: SUNSHINE
• Product Name: Unlimited Film Cutting Machine
• Model: Y22 Plus
• Net Weight: About 7kg
• Gross Weight: About 9kg
• Product Size: 630*180*170mm
• Package Size: 660*310*265mm
• Feeding Width: 360mm
• Cutting Accuracy: ±0.1mm
• Repeat Accuracy: ±0.1mm
• Cutting Speed: 300-500mm/s
• Cutting Pressure: 30-90 digital gears (corresponding to pressure 150~1000g)
• Data Transmission Method: Mobile phone Bluetooth APP data output/machine connection WiFi output
• Input Current/Voltage: DC 24V=2.75A
• Power: <65W

Package includes:

• 1 x Host
• 1 x Power Adapter
• 3 x Scraper
